FUSION//AERO ROAD DISC FRAMESET

In stock
The REILLY FUSION represents an evolution of Reilly’s road series, combing classic Reilly race geometry, top grade hydroformed titanium tubes, and advanced engineering to create a light, aerodynamic titanium frame to rival carbon equivalents.  In a nod to tradition, Reilly’s innovative use of investment casting makes the FUSION a distinctive ti offering in a market of ubiquitous carbon frames.
The nature of investment casting allowed Reilly to mimic the aero shapes usually associated with a carbon mould or 3D printing.  The seamless welding of the investment cast parts to 3AL-2.5V tubing highlights the hand-crafted detail associated with all Reilly frames.  Fully integrated cable routing gives the bike a sleek and minimal cockpit, while the stunning ‘kamm tail’ tube profile brings additional aero benefit.
Neil FitzGerald, Reilly Co-founder, says of the launch: “Reilly’s Fusion is spearheading the titanium road revolution. It symbolises an exciting time for us, marking a new chapter as we build on our framebuilding heritage, while continuing to innovate to offer all customers their dream ride. We have raised the bar again for road adventurers to create a truly cutting edge bicycle frame to enjoy the great outdoors, whether that’s planning an ultra endurance road trip or sleekly navigating the daily commute.”
TO BOOK A DEMO RIDE OR FOR HELP WITH FULL BIKE BUILDS CONTACT PHIL 01273 694 143 / SALES@REILLYCYCLEWORKS.COM
Regular price £3,999.00 incl VAT for UK customers ONLY
Size

Share the Fusion with your friends.

BOOK A DEMO RIDE HERE

Titanium Grade  6AL-4V and 3AL -2.5V
Fork Carbon race fork with internal front brake hose routing
Headset Fully integrated as chosen
Frame Features x2 Bottle cage mounts
Warranty   Lifetime Frame Warranty (Original Owner Only, Non-Transferable) T&Cs Apply


Frame Geometry

SIZE EXTRA SMALL SMALL MEDIUM LARGE EXTRA LARGE
SEAT TUBE C/TOP 470mm 490mm 510mm 530mm 540mm
TOP TUBE EFFECTIVE 510mm 530mm 547mm 570mm 590mm
BB DROP 72mm 72mm 72mm 72mm 72mm
CHAINSTAY LENGTH 414mm 414mm 414mm 414mm 414mm
SEAT TUBE ANGLE 75.5° 74° 73.5° 73° 73°
HEAD TUBE ANGLE 71.5° 72° 73° 73° 73°
FORK RAKE 43mm 43mm 43mm 43mm 43mm
FRONT CENTRE 577mm 577mm 579mm 597mm 617mm
WHEELBASE 980mm 980mm 982mm 1000mm 1020mm
HEAD TUBE 110mm 130mm 150mm 170mm 185mm
STACK 512mm 533mm 555mm 574mm 589mm
REACH 378mm 377mm 382mm 394mm 410mm

GCN Tech - This Reilly Fusion is UNBELIEVABLE 😍

James Spender / Cyclist.  Read the 4.5 star review here

The Reilly Fusion is an absolute stunner of a bike to look at and an unalloyed joy to ride

Stu Kerton / Road.cc 9/10 review here

Excellent bike with the performance and looks of carbon but the stunning comfort and longevity of titanium
